How to use the MG4800 Wireless Grip Dynamometer (with Charder Connect App)

1) Download Charder Connect App from Google Play (Android Devices) or the App Store (iOS Devices)


Android Devices	iOS Devices

2) After opening app, create master account

There are two types of accounts in the Charder Connect App: Administrator accounts, and User accounts. Measurements are conducted using User accounts, which can be created after you login using an Administrator account.

Input Account and Password, and press Register new account. In the future, you will login using this account.

NOTE: Because the Charder Connect App is used offline without the need for an internet connection, there is also no way to recover your password if you forget it!

3) Create user account (as many as needed)

Press Add new user

Input info as prompted. Please note that duplicate IDs are not allowed!
Charder Connect Add New User

4) Pair with device

Select user account for measurement

Press human-shaped icon on the right to begin pairing with device

(Press "accept" to permissions required, such as Bluetooth permissions)

Press pairing icon on the top right

Turn on the MG4800 Wireless Dynamometer by pressing the [Power/Zero] key

It will appear on the "new device" list as a "Dynamometer". Press [Select] key.

After selection, we can see that the MG4800 is now paired with Charder Connect, and the wireless icon on the MG4800's screen should appear.

5) Device setup

The MG4800 has 3 modes: Real Mode, Max Mode, and Target Mode.

In Real Mode, the MG4800 will dynamically display the force exerted, which changes in real time as the user squeezes and lets go.

In Max Mode, the MG4800 will record the maximum force.

In Target Mode, a target force will be set (ex: 20 kg), and the MG4800 will record how many measurements exceeded this target, as well as the average of the last two results.

To transfer measurement results, the device must be in Target Mode. Press [Set] key to enter Target Mode. By default, target is 20 kg - you can press [Mode] key to increase (press and hold to increase faster). Press [Set] key to confirm target.

Begin using MG4800. Device will automatically record every result that exceeds target.

After measurement is complete, press [Power/Zero] key to transfer results to Charder Connect.

Press [Save] key to save results, or [Clear] key to discard. You can press "Right" or "Left" on the screen to specify which hand was used for each measurement.
